AC Current Probe Model MN379T

AC current probe Model MN379T (5A, 200mV/A & 100A, 10mV/A, 10ft. BNC Lead)
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status Distributor Stock Check
MN379T 2153.02 AC current probe Model MN379T
(5A, 200mV/A & 100A, 10mV/A, 10ft. BNC Lead)
$269.00 Consult Factory for Availability
ModelMN379T
Cat. #2153.02
DescriptionAC current probe Model MN379T
(5A, 200mV/A & 100A, 10mV/A, 10ft. BNC Lead)
List Price$269.00
Consult Factory for Availability
Print
Maximum Conductor Size 0.78" (20mm), bus bar 20x5mm
Current Range 0.005 to 5A, 0.1 to 100A
Measurement Range 0.005 to 6A, 0.1 to 120A
Output 10ft (3m) lead with BNC output
Transformation Ratio N/A
Output Signal 200mV/A AC (1V @ 5A) & 10mV/A AC  (1V @ 100A)
Accuracy 50/60Hz 1% @ 5A & 1% @ 100A
Frequency Range 40Hz to 10KHz
Phase Shift At 50Hz 4° @ 5A & 2.2 ° @ 100A
Open Secondary Voltage N/A
Load Impedance 1MΩ
Overload 200A continuous
Dimensions  (H x W x D) 5.47 x 2.00 x 1.18” (139 x 51 x 30mm)
Weight 6.5 oz (180g)
Operating Temperature 14° to +131°F  (-10° to +55°C)
Storage Temperature -40° to +158°F  (-40° to +70°C)
Operating Humidity 90% RH
Pollution Degree 2
Ingress Protection (IP) IP40
EMC EN 61326-1
Safety Compliance Category CAT III, EN/IEC 61010-032
