Lightmeter Data Logger Model 1110

The Lightmeter Model 1110 is a portable, easy-to-use instrument which features optical sensors that are designed to match the response of the human eye, making them ideal instruments for workspace analysis and planning. The main advantage of the logger is its ability to perform a variety of recording tasks with easy and intuitive setup from a computer using supplied DataView® software. The ergonomically designed case, large display and intuitive function selection make this instrument the right choice for any application.
The Lightmeter Model 1110 is designed for simple one-hand operation. It provides selectable lux or footcandle units for display and features a blue luminescent backlit display, MIN/MAX/AVG and HOLD functions.
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status Distributor Stock Check
1110 2121.71 Lightmeter Data Logger Model 1110 $389.00 Out of Stock Consult Factory for Availability
Model1110
Cat. #2121.71
DescriptionLightmeter Data Logger Model 1110
List Price$389.00
Out of Stock Consult Factory for Availability
Print
Channel One with LCD display and Backlight
Input Detachable silicon (Si) sensor Class C Lightmeter per NF C 42-710
Accuracy ±3% of R on incandescent sources (default mode)
±6% of R on LEDs (3000K to 6000K)
±9% of R on florescent sources
Accuracy with compensation LED mode: ±4% of R (at 4000K)
Flou mode: ±4% of R (type F11, 4000K)
Resolution 0.1lux from 0.1 to 999.9lx
1lx from 1000 to 9.999lx
10lx from 10.00klux to 99.99klx
100lx beyond
0.01fc from 0.01 to 99.99fc
0.1fc from 100.0 to 999.9fc
1fc from 1.000 to 9.999fc
10fc beyond
Recording Manual start/stop on the product
Short press for MEM: spot recording/long press for REC at the define default rate
Programed recording: start date, recording interval, and end date defined using DataView® software
Other functions MIN-AVG-MAX-HOLD
Sampling Rate Programmable from 1s, 2s, 5s, 10s, 20s, 30s, 2min, 5min, 10min, 15min, 30min, and 1hr
MAP mode The MAP mode can be used to map the lighting on a surface of a room. In this case the measurements are saved in the same file
Memory 1,000,000 measurements on each channel (4MB). Recorded data is stored in non-volatile memory and will be retained even if battery is low or removed.
Communication USB 2.0 and Bluetooth
Power Source 3x1.5V AA(LR6) alkaline batteries or USB port (micro-USB adaptor offered as an accessory)
Battery Life 500 hrs., 3 years with 15 minute intervals
Dimensions:     Case
                       Sensor
5.9 x 2.84 x 1.28" (150 x 72 x 32mm)
2.64 x 2.52 x 1.38" (67 x 64 x 35mm)
Weight (with battery) 12.2oz (345g) with batteries
Case Polycarbonate
Operating Temperature 14° to 140° F (-10° to 60°C)
Storage Temperature -4° to 140° F (-20° to 60°C)
Relative Humidity Up to 90%
Ingress Protection (IP) IP50 with USB connector closed and protective cap on the sensor
EMC EN 61326-1
Safety Compliance IEC 61010-1
Warranty 2 years
