AC Current Probe Model C177A

The AC Current Probe Model C177A features a measurement range of 5mA to 200A, with a transformation ratio of 10,000:1. Its maximum clamping diameter is 2.05" (52mm). The probe includes a 6.5' (2m) lead with proprietary CA connector. The Model C177A is designed for use with Multi-Function Installation Testers Models C.A 6116/6116N, and C.A 6117.
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status
C177A 2138.52 AC Current Probe Model C177A $370.00
ModelC177A
Cat. #2138.52
DescriptionAC Current Probe Model C177A
List Price$370.00
Print
Meter Compatibility C.A 6116N, C.A 6117
Maximum Clamping Diameter 2.05" (52mm)
Current Range 200A
Measurement Range 0.05 to 200A
Transformation Ratio 10,000:1
Output 6.5ft (2m) lead with proprietary CA connector
Operating Temperature 32° to +113°F  (0° to +45°C); 90% RH
Storage Temperature -40° to +158°F  (-40° to +70°C)
Operating Relative Humidity 90% RH
Dimensions  (HxWx D) 8.50 x 4.37 x 1.77” (216 x 111 x 45mm)
Weight 1.21 lb (550g)
Pollution Degree 2
Ingress Protection IP 40, IP 30 with jaws open
Safety Compliance IEC 61010-2-032, EN 61010-1, EN61010-031 300V CAT IV,
600V CAT III
Model Cat. # Description List Price Quantity/Status
1017.45 Adapter - 4mm Non-insulated for Safety Leads $18.00
2118.09 General Carrying Case
Dimensions: 13 x 9.5 x 3"
$56.00
2118.46 Adapter - Banana (Female) - BNC (Male) (XM-BB) for use with AmpFlex Sensors, Models K100/K110 and SLII Data Loggers
(600V CAT III)
$44.00
2119.94 Adapter - BNC (Female) to 4mm Banana (Male) 600V CAT III $15.50
2133.72 Compact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
$29.95
2133.73 Bag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336 & PEL105
Dimensions: 18 x 9 x 12"
$44.00
2140.52 Clip - Safety Alligator - Red {Rated 1000V CAT IV, 15A, UL} $7.25
2140.53 Clip - Safety Alligator - Black {Rated 1000V CAT IV, 15A, UL} $7.25
2140.54 Clip - Safety Alligator - Blue {Rated 1000V CAT IV, 15A, UL} $7.25
2140.55 Clip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL} $7.25
2140.56 Clip – Set of 4, Safety Alligator (Red, Black, Blue & White) {Rated 1000V CAT IV, 15A, UL} $30.50
2152.24 Lead - Set of 2, Color-coded (red/black) 5 ft Safety Leads (1000V CAT IV)
Replacement for 2140.57
$20.50
Model
Cat. #1017.45
DescriptionAdapter - 4mm Non-insulated for Safety Leads
List Price$18.00
Model
Cat. #2118.09
DescriptionGeneral Carrying Case
Dimensions: 13 x 9.5 x 3"
List Price$56.00
Model
Cat. #2118.46
DescriptionAdapter - Banana (Female) - BNC (Male) (XM-BB) for use with AmpFlex Sensors, Models K100/K110 and SLII Data Loggers
(600V CAT III)
List Price$44.00
Model
Cat. #2119.94
DescriptionAdapter - BNC (Female) to 4mm Banana (Male) 600V CAT III
List Price$15.50
Model
Cat. #2133.72
DescriptionCompact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
List Price$29.95
Model
Cat. #2133.73
DescriptionBag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336 & PEL105
Dimensions: 18 x 9 x 12"
List Price$44.00
Model
Cat. #2140.52
DescriptionClip - Safety Alligator - Red {Rated 1000V CAT IV, 15A, UL}
List Price$7.25
Model
Cat. #2140.53
DescriptionClip - Safety Alligator - Black {Rated 1000V CAT IV, 15A, UL}
List Price$7.25
Model
Cat. #2140.54
DescriptionClip - Safety Alligator - Blue {Rated 1000V CAT IV, 15A, UL}
List Price$7.25
Model
Cat. #2140.55
DescriptionClip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL}
List Price$7.25
Model
Cat. #2140.56
DescriptionClip – Set of 4, Safety Alligator (Red, Black, Blue & White) {Rated 1000V CAT IV, 15A, UL}
List Price$30.50
Model
Cat. #2152.24
DescriptionLead - Set of 2, Color-coded (red/black) 5 ft Safety Leads (1000V CAT IV)
Replacement for 2140.57
List Price$20.50
