  • Product meets UL established electrical standards.

AC Current Probe Model SR600

The SR600 is a general purpose 1000AAC current probe designed for use with DMMs, loggers and other instruments that have a current input. It has a 1000:1 ratio and output of 1mA per amp measured in the jaw. The SR600 has jack output termination that accept 4mm banana plugs. The rounded jaw design on this probe makes it well-suited for power applications where high accuracy and low phase shift is important.
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status Distributor Stock Check
SR600 2113.42 AC Current Probe Model SR600 $184.00 Consult Factory for Availability
ModelSR600
Cat. #2113.42
DescriptionAC Current Probe Model SR600
List Price$184.00
Consult Factory for Availability
Print
Maximum Conductor Size 2.05" (52mm)
Current Range 1000Arms AC
Measurement Range 0.1 to 1200A
Output Two standard banana jack (4mm)
Transformation Ratio 1000:1
Output Signal 1mA/AAC (1A @ 1000A)
Accuracy 50/60Hz 0.5% @ 1000A
Frequency Range 30Hz to 5KHz
Phase Shift at 50Hz 0.5° @ 1000A
Open Secondary Voltage None
Load Impedance 1Ω, 5Ω max with derating
Overload 1200A for 40 mn ON then 20 mn OFF
Dimensions  (H x W x D) 4.37 x 8.50 x 1.77” (111 x 216 x 45mm)
Weight  1.21 lbs (550g)
Operating Temperature 14° to +122°F  (-10° to +50°C)
Storage Temperature -4° to +158°F  (-20° to +70°C)
Operating Humidity 90% RH
Pollution Degree 2
Ingress Protection (Ip) IP40
EMC EN 61326-1
Safety Compliance EN/IEC 61010-1 600V CAT III,
EN/IEC 61010-032

User Manuals

Datasheets

Comparison Charts

Application Notes

Model Cat. # Description List Price Quantity/Status Distributor
Stock Check
1017.45 Adapter - 4mm Non-insulated for Safety Leads $18.00 Consult Factory for Availability
2118.09 General Carrying Case
Dimensions: 13 x 9.5 x 3"
$60.00 Consult Factory for Availability
2133.72 Compact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
$33.50
2133.73 Bag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336, 8436 & PEL105
Dimensions: 18 x 9 x 12"
$49.00
2140.53 Cat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).; $8.50
2140.55 Clip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL} $8.50
5100.00 Clip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2) $9.50 Consult Factory for Availability
5100.04 Clip - Safety Alligator - Blue (1000V CAT IV, 15A, UL V2) $9.50
5100.07 Lead - set of 2, 5 ft color-coded (red/black) PVC w/ 4mm ST/ST plugs $24.00
Model
Cat. #1017.45
DescriptionAdapter - 4mm Non-insulated for Safety Leads
List Price$18.00
Consult Factory for Availability
Model
Cat. #2118.09
DescriptionGeneral Carrying Case
Dimensions: 13 x 9.5 x 3"
List Price$60.00
Consult Factory for Availability
Model
Cat. #2133.72
DescriptionCompact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
List Price$33.50
Model
Cat. #2133.73
DescriptionBag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336, 8436 & PEL105
Dimensions: 18 x 9 x 12"
List Price$49.00
Model
Cat. #2140.53
DescriptionCat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).;
List Price$8.50
Model
Cat. #2140.55
DescriptionClip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL}
List Price$8.50
Model
Cat. #5100.00
DescriptionClip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2)
List Price$9.50
Consult Factory for Availability
Model
Cat. #5100.04
DescriptionClip - Safety Alligator - Blue (1000V CAT IV, 15A, UL V2)
List Price$9.50
Model
Cat. #5100.07
DescriptionLead - set of 2, 5 ft color-coded (red/black) PVC w/ 4mm ST/ST plugs
List Price$24.00
