Model | Cat. # | Description | List Price | Quantity/Status | Distributor Stock Check |
---|---|---|---|---|---|
SL12 | 2156.12 | Simple Logger® Model SL 12 (Voltage, 10VDC) | $149.00 |
|
|
|
Channels | One |
Input | Screw connector |
Range | (-10 to 10) VDC |
Accuracy (50/60Hz) | ±(0.5 % R +50 mV) with filter set to 10 |
Resolution | 10 mV |
Maximum Input Voltage | 60 VDC |
Input Impedance | 800 kΩ |
Sample Rate | 16 samples/second |
Storage Rate | 1 second |
Storage Modes | Start/Stop |
Recording Length | ≥ 43 days |
Memory | 4 million measurements (8MB). Recorded data is stored in non-volitile memory and will be retained even if battery is low or removed. |
Communication | USB 2.0 (Simple Logger software free to download from web site) |
Power Source | (2) 1.5 V AA (LR6) alkaline batteries or USB 5VDC When powered by USB, the battery is automatically disconnected. |
Battery Life | 43 days with new batteries when recording |
Low Battery | Battery voltage display in software (Batteries need replacement when the LED is dim or does not blink) |
Dimensions | (3.6 x 1.44 x 1.32) in (91.44 x 36.58 x 34.8) mm |
Weight (with battery) | 3.5 oz (99 g) |
Case | Polycarbonate |
Operating Temperature | (14 to 122)°F (-10 to 50) °C |
Storage Temperature | (-4 to 140) °F (-20 to 60) °C |
Relative Humidity | Up to 85 % @ 95 °F (35 °C) |
Ingress Protection (IP) | IP40 |
EMC | EN 61326-1 |
Safety Compliance | IEC 61010-1 |
