Clamp-on Meter Model 606

Introducing the TRMS Power Clamp-on Meter Model 606

Elevate your electrical testing capabilities with the TRMS Power Clamp-on Meter Model 606, a cutting-edge tool designed to meet the demands of even the most discerning professionals. This versatile meter boasts an impressive range of measurement capabilities, including AC voltage up to 1200 V, DC voltage up to 1700 V, current measurement up to 2000 AAC and 3000 ADC, and active power up to 2400 kW AC and 5100 kW DC.

Unmatched Safety and Durability for Demanding Environments

Safety is paramount when working with electricity, and the TRMS Power Clamp-on Meter Model 606 doesn't compromise on this crucial aspect. With its safety rating of 1000 V CAT IV and 1500 V CAT III, you can operate confidently in even the most demanding electrical environments. Its IP54 rating ensures resilience against dust and water spray, making it ideal for harsh industrial settings.

Ergonomic Design for Effortless One-Handed Operation

The TRMS Power Clamp-on Meter Model 606 prioritizes user-friendliness, featuring an ergonomic design that allows for effortless one-handed operation. Easily navigate function selection and button pushing, even with gloves on.

Functionality for Comprehensive Electrical Analysis

Beyond the standard measurements of volts, amps, frequency, resistance, diode checking, and continuity, the Model 606 offers a suite of unparalleled functions, including:

  • True InRush® for capturing motor start-up currents
  • Delta relative function for tracking changes in measurements
  • Phase rotation indication for ensuring proper wiring connections
  • Comprehensive power measurements for analyzing energy consumption
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status Distributor Stock Check
606 2139.62 Power Clamp-on Meter Model 606 $495.00
Model606
Cat. #2139.62
DescriptionPower Clamp-on Meter Model 606
List Price$495.00

Model 605 - Cat. #2139.62: Includes soft carrying case, set of (2) color-coded silicone insulated (red/black), test probes and alligator clips (red/black), (4) 1.5 V AA batteries, and a user manual.

Print
Voltage Range DC: 1700 Vrms Autoranging
Voltage Range AC: 1200 Vrms Autoranging
Resolution: (0.01 to 1) V
Current Range: 2000 Arms AC, 3000 ADC
Resolution: (0.01 to 1) A
Accuracy V Typical: 1 % ± 3 cts up to 1000 A
Accuracy A Typical: 1 % ± 3 cts up to 1000 A
True InRush®: 20 A to 2000 AAC, 3000 ADC
Continuity: Selectable from (0 to 999.9) Ω
Resistance: 100 kΩ
Diode Test: (0 to 3.2) VDC
Active and Apparent Power: 0 W to 5100 kW DC, 5 W to 2400 kW AC
Power Factor: -1.00 to +1.00
THD: (0.0 to 100) % THDr, (0.0 to 1000) THDf
Frequency: 5 Hz to 20 kHz in V
5 Hz to 1kHz in A
Phase Order Indication: (50 to 1200) V from (47 to 400) Hz
MIN/MAX Yes
LCD w/backlight Yes
Power Source: (4) AA, NEDA 15 A, IEC LR6
Battery Life: > 350 h
Dimensions: (11.65 x 4.37 x 1.61) in (296 x 111 x 41) mm
Weight: 1.32 lbs (600 g) with batteries
Jaw Opening: 2.36 in (60 mm)
Operating Temperature: (-4 to 131) °F (-20 to 55) °C
Storage Temperature: (-40 to 158) °F (-40 to 70) °C
Operating Humidity: 90 % up to 131 °F (55 °C)
Pollution Degree: 2
Ingress Protection: IP54 (Housing)
EMC: EN61326-1
Safety Compliance: EN/IEC 61010-1
EN/IEC 61010-2-030
EN/IEC 61010-032 to 1000 V CAT IV, 1500 V CAT III

User Manuals

Datasheets

Brochures

Comparison Charts

Application Notes

Videos

400 & 600 Clamp On Series Instructional Presentation

Model Cat. # Description List Price Quantity/Status Distributor
Stock Check
2121.05 AC Line Splitter Model ALS-1 $18.00
2139.71 Thermocouple – K-thermocouple w/4mm Integrated Adapter (Replacement for Models 1821,1822, 5233, 5217, MTX 3292B/92B-BT/93B/93B-BT, 203, 401, 403, 601, 603, 607, 675 & 5217) $14.00
2139.72 Replacement Pouch for Clamp-on Meter Models 401, 403, 405, 601, 603 & 605 and Megohmmeter Models 6528 & 6529. Dimensions: 13.54 x 4.75 x 2.75” $18.95
5000.30 Probe - black test probe {Rated 1000V CAT IV, 15A, UL} replacement for Megohmmeter lead sets $6.00
5000.94 Lead - set of 2, 5 ft silicone color-coded (red/black) with 4mm straight/right banana plugs (Rated 1000V, CAT IV, UL) $26.50
5000.98 Probe - red test probe {Rated 1000V CAT IV, 15A, UL V2} $9.00
5000.99 Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2) $11.50
5100.00 Clip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2) $11.50
Model
Cat. #2121.05
DescriptionAC Line Splitter Model ALS-1
List Price$18.00
Model
Cat. #2139.71
DescriptionThermocouple – K-thermocouple w/4mm Integrated Adapter (Replacement for Models 1821,1822, 5233, 5217, MTX 3292B/92B-BT/93B/93B-BT, 203, 401, 403, 601, 603, 607, 675 & 5217)
List Price$14.00
Model
Cat. #2139.72
DescriptionReplacement Pouch for Clamp-on Meter Models 401, 403, 405, 601, 603 & 605 and Megohmmeter Models 6528 & 6529. Dimensions: 13.54 x 4.75 x 2.75”
List Price$18.95
Model
Cat. #5000.30
DescriptionProbe - black test probe {Rated 1000V CAT IV, 15A, UL} replacement for Megohmmeter lead sets
List Price$6.00
Model
Cat. #5000.94
DescriptionLead - set of 2, 5 ft silicone color-coded (red/black) with 4mm straight/right banana plugs (Rated 1000V, CAT IV, UL)
List Price$26.50
Model
Cat. #5000.98
DescriptionProbe - red test probe {Rated 1000V CAT IV, 15A, UL V2}
List Price$9.00
Model
Cat. #5000.99
DescriptionClip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)
List Price$11.50
Model
Cat. #5100.00
DescriptionClip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2)
List Price$11.50
