AC Current Probe Model MN93-BK

The AC Current Probe Model MN93-BK features 10’ leads and 200A capacity. This probe is designed for use with the following instruments: Models 3945/3945-B, 8220, 8230, 8333, 8335, 8336, PEL Series, L104 and L564.
NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.
Model Cat. # Description List Price Quantity/Status Distributor Stock Check
MN93-BK 2140.32 AC Current Probe Model MN93-BK $194.00 Consult Factory for Availability
MN93-BK 2140.32 AC Current Probe Model MN93-BK $194.00 Consult Factory for Availability
ModelMN93-BK
Cat. #2140.32
DescriptionAC Current Probe Model MN93-BK
List Price$194.00
Consult Factory for Availability
ModelMN93-BK
Cat. #2140.32
DescriptionAC Current Probe Model MN93-BK
List Price$194.00
Consult Factory for Availability
Print
Clamping Diameter 0.78” (20mm)
Current Range 240AAC
Measurement Range 0.5 to 240AAC
Lead Length 10 ft (3m)
Output Termination Proprietary connector
Accuracy (Typical) ±1%
Power Source N/A
Compatibility AEMC PowerPads and PELs (limited range with models 8220 and 8230)
Operating Temperature 14° to +131°F  (-10° to +55°C); 10 to 85% RH
Storage Temperature -40° to +158°F  (-40° to +70 °C); 10 to 90% RH
Dimensions 5.47 x 2.0 x 1.18” (135 x 51 x 30mm)
Weight 24 oz (690g)
Pollution Degree 2
Protection IK 04, IP40 (jaws closed), IP30 (jaws open)
Safety Compliance IEC 61010-1, IEC 61010-2-032, 600V CAT III, 300V CAT IV

User Manuals

Comparison Charts

Application Notes

Model Cat. # Description List Price Quantity/Status Distributor
Stock Check
1017.45 Adapter - 4mm Non-insulated for Safety Leads $18.00 Consult Factory for Availability
2118.09 General Carrying Case
Dimensions: 13 x 9.5 x 3"
$60.00 Consult Factory for Availability
2133.72 Compact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
$33.50
2133.73 Bag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336, 8436 & PEL105
Dimensions: 18 x 9 x 12"
$49.00
2140.53 Cat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).; $8.50
2140.55 Clip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL} $8.50
5100.00 Clip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2) $9.50 Consult Factory for Availability
5100.04 Clip - Safety Alligator - Blue (1000V CAT IV, 15A, UL V2) $9.50
5100.07 Lead - set of 2, 5 ft color-coded (red/black) PVC w/ 4mm ST/ST plugs $24.00
Model
Cat. #1017.45
DescriptionAdapter - 4mm Non-insulated for Safety Leads
List Price$18.00
Consult Factory for Availability
Model
Cat. #2118.09
DescriptionGeneral Carrying Case
Dimensions: 13 x 9.5 x 3"
List Price$60.00
Consult Factory for Availability
Model
Cat. #2133.72
DescriptionCompact tool bag for field use.
12 Exterior and 14 Interior pockets
Dimensions: 13.0 x 9.8 x 9.5"
List Price$33.50
Model
Cat. #2133.73
DescriptionBag – Extra Large Classic Tool Bag Replacement for Models 3945/3945-B, 6240, 6250, 6471, 6505, 5050, 5060, 5070, 8333, 8335, 8336, 8436 & PEL105
Dimensions: 18 x 9 x 12"
List Price$49.00
Model
Cat. #2140.53
DescriptionCat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).;
List Price$8.50
Model
Cat. #2140.55
DescriptionClip - Safety Alligator - White {Rated 1000V CAT IV, 15A, UL}
List Price$8.50
Model
Cat. #5100.00
DescriptionClip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2)
List Price$9.50
Consult Factory for Availability
Model
Cat. #5100.04
DescriptionClip - Safety Alligator - Blue (1000V CAT IV, 15A, UL V2)
List Price$9.50
Model
Cat. #5100.07
DescriptionLead - set of 2, 5 ft color-coded (red/black) PVC w/ 4mm ST/ST plugs
List Price$24.00
